Acrylic Copolymer Membrane


Cobetter Acrylic Copolymer Membrane is acrylic copolymer membrane cast on nonwoven nylon support. It is both hydrophobic and oleophobic material with great air permeability and broad chemical compatibility, the oil rating could be up to 8 grade (AATCC 118-2013). Non-wettable by most low surface tension liquids and high air flow rate makes it an ideal material for a variety of air venting applications, which has same good performance as Versapor*.


Benefit from the casting process and robust support layer, acrylic copolymer membrane is one of the durable materials, which makes it compatible with multiple welding methods, including ultrasonic welding, torsional welding, thermal welding, RF welding, insert welding etc. The special construction of the membrane makes the welding easier, both sides could be welded without distinguishing. The simple handling feature improves the labor efficiency.


Cobetter Acrylic Copolymer membrane withstands Ethylene Oxide(EtO), E-Beam, Gamma Irradiation (Up to 50KGY) and steam sterilization, providing compatibility to the stringent sterilization requirements in medical applications. In addition, our membrane complies with United States Pharmacopeia(USP) Biological Reactivity Tests,In Vivo<88>for biosafety and is non-cytotoxic.

Cobetter Acrylic Copolymer Membrane.png

This membrane has good compatibility with a wide range of housing/plastic materials: High Density Polyethylene(HDPE), Low Density Polyethylene(LDPE), Polypropylene(PP), Acrylonitrile Butadiene Styrene(ABS), Polycarbonate(PC), Polymethyl Methacrylate(PMMA) etc. Due to the characteristics of non-woven nylon support, it is also suitable for high-frequency welding of PVC, EVA and other soft bags films. The peel strength after welding is superior to any other membranes, and it has advantages in the special application of urine bag and drainage bag.

*Versapor is a trademark of Pall Corporation.


PFOA Free
Cobetter can supply PFOA free membrane filter that do not contain Perfluorooctanoic acid (PFOA), its salts and PFOA-related substances, which comply with relative regulation requirements in European REACH EU2017/1000, EC1907/2006 (REACH), and POP EU2020/784.




Features and Benefits

• Robust air/ gas filtration and venting performance over a broad range of operating conditions.

• Strong Physical Integrity, resistance to low surface-tension fluids.

• Reduce the risk of bacterial/particulate contamination.

• Flexible welding with both sides.

• Ideal choice for medical device venting and liquid barrier application.



Application

• IV Filter Vent

• Urine meters / bags

• Ostomy pouches

• IV spike

• Dispensing pin

• Suction canisters


Production Diagram of Cobetter Acrylic Copolymer Membrane-07.pngProduction Diagram of Cobetter Acrylic Copolymer Membrane-03.pngProduction Diagram of Cobetter Acrylic Copolymer Membrane-02.png
Production Diagram of Cobetter Acrylic Copolymer Membrane-06.pngProduction Diagram of Cobetter Acrylic Copolymer Membrane-04.pngProduction Diagram of Cobetter Acrylic Copolymer Membrane-05.png




Specification

Acrylic copolymer membrane on nonwoven nylon support



Available Pore Size

0.2μm,  0.45μm,  0.8μm,  1.2μm, 3μm, and 5μm



Biological Safety

Meets USP<88>, for class VI-121℃ plastic



Sterilization

Ethylene Oxide, E-Beam, Gamma Irradiation, Steam Sterilization.



Available Format

Roll , Sheet , Disc , Customization.



  Compatible Materials / Methods

    Acrymer Copolymer Membrane

  Housing / Plastics Materials

    HDPE, LDPE, PP, ABS, PC, PMMA, PVC, EVA etc.

  Welding Methods

   Ultrasonic welding, Torsional welding, Thermal welding, RF welding, Insert molding etc

  Sterilization Methods   Ethylene Oxide, E-Beam, Gamma Irradiation, Steam Sterilization.



For technical data sheet or application inquiry, you are more than welcome to contact our sales representative by sales@cobetterfilter.com or leave a message
